Sandia researchers say better materials and manufacturing techniques for nanowires could allow car makers to harvest power from the heat wasted by exhaust systems or lead to more efficient devices to cool computer chips.
The work, “Using galvanostatic electroforming of Bi1-xSbx nanowires to control composition, crystallinity, and orientation,” published in the Materials Research Society’s Journal of Materials Research was the first time researchers managed to control crystal orientation, crystal size, and alloy uniformity by a single process. All three factors contribute to better thermoelectric performance, said Graham Yelton of Sandia’s Physics Based Microsystems Dept. “The three together mean a huge gain, and it’s hard to do,” he said. “It’s turning the knobs of the process to get these things to behave.”
Better nanowire geometries can reduce heat conductivity and improve what’s called the thermoelectric figure of merit, a measure of a material’s electrical and thermal conductivity. The higher the electrical conductivity and the lower the thermal conductivity, the higher the figure of merit and, therefore, the more efficient the material. However, the quality of previous thermoelectric nanowires proved inadequate.
Despite their inefficiency, some thermoelectric materials are already in use. Yelton compares their stage of development to the early days of solar photovoltaic cells: Everyone saw the potential, but they were so inefficient they were used only when nothing else worked. Improved efficiency in nanowires would increase the use of thermoelectric materials. They’re already used in some sensors, and vehicle manufacturers hope they can harvest heat from exhaust systems to power vehicle sensor systems, Yelton said.
Sandia’s paper describes how the team created thermoelectric nanowire arrays with uniform composition along the length of the nanowire and across the spread of the nanowire array, which potentially can include hundreds of millions of nanowires. In addition, they created nanowire crystals of uniform size and orientation, or direction. Uniform composition improves efficiency, while orientation is important so electrons, the carriers of energy, flow better.
The next step is more challenging: making an electrical contact and studying the resulting thermoelectric behavior. “Thermoelectric materials readily form oxides or intermetallics, leading to poor contact connections or higher electrical contact resistance. That reduces the gains achieved in developing the materials,” Yelton said.
While the Sandia team has been able to get good contact at the bottom of an array, making a connection at the top has proved difficult, he said. “To make a contact and measure array performance is not trivial,” Yelton said. He and his colleagues are seeking further funding to solve the problem of successfully making contacts, and then to characterize the thermal electric properties of arrays. “If successful at the labs, we would try to find an industry collaborator to mature the idea,” he said.
Read the Sandia news release.
Keywords:
- better materials and manufacturing techniques
- galvanostatic electroforming to control nanowire composition
- galvanostatic electroforming to control nanowire crystallinity
- galvanostatic electroforming to control nanowire orientation
- improve thermoelectric figure of merit
- Journal of Materials Research
- Materials Research Society
- MRS
- reduce heat conductivity
- SAND2015-1371M
- thermoelectric nanowire efficiency
February 26, 2015
